70 PD45 User Guide
Ethernet
To view these settings:
• From the printer Main Menu, select Settings > Communications > Ethernet.
• From the printer web page, click the Configure tab. Go to Communications >
Ethernet.
Media Settings
To view these settings:
• From the printer Main Menu, select Settings > Printing > Media.
• From the printer web page, click the Configure tab. Go to Printing > Media.
Ethernet Setting Description Default
(IPv4) IP Assignment
Method
Specifies how the printer obtains an IP address. DHCP
(IPv4) IP Address Specifies the unique network-level address that is
assigned to each device in a TCP/IP network (IPv4).
0.0.0.0
Subnet Mask Specifies a number that defines the range of IP addresses
that can be used in a TCP/IP network.
0.0.0.0
Default Router Specifies the IP address of a router that is used when a
device sends a packet to another subnet or to an
unknown destination.
0.0.0.0
DHCP Response Specifies if the printer receives DHCP responses by
broadcast or unicast.
Broadcast
(IPv6) IP Assignment
Method
Specifies how the printer obtains an IP address (for IPv6
networks).
Automatic
(IPv6) IP Address Specifies the unique network-level address that is
assigned to each device in a TCP/IP network (IPv6).
Automatic

Honeywell PD45 Specifications

General

Print Technology	Direct Thermal / Thermal Transfer
Ribbon Core	1 inch (25.4 mm)
Print Resolution	203 dpi
Max Print Width	4.25 inches (108 mm)
Max Print Speed	8 ips (203 mm/s)
Connectivity	USB 2.0, RS-232, Ethernet
Media Handling	Label gap, label black mark
Media Thickness	0.0025 inch to 0.01 inch (0.0635 mm to 0.254 mm)
Ribbon Width	1 inch to 4.33 inches (25.4 mm to 110 mm)
Ribbon Length	984 feet (300 meters)
Operating Temperature	5°C to 40°C (41°F to 104°F)
Power Requirements	100-240 VAC, 50/60 Hz
Media Width	25.4 mm (1 in) to 118 mm (4.65 in)
