34 PD45 User Guide
Printer Configuration
Configure the Printer from the Main Menu
You can view or change the configuration settings by pressing the Settings button
from the Main Menu.
1. From the Ready screen, press the Main Menu button.
2. From the Main Menu, press the Settings button. The Settings menu appears.
3. Select the settings you want to configure and make your changes.
4. Save your changes when prompted.
Restrict Access to the Main Menu
By default, all menus are available from the Main Menu the first time you turn on
the printer. If necessary, you can require a PIN to restrict access to menus or you
can disable access to all menus.
1. Go to the Display menu for the printer:
From the web page (see Smart Printing), select Configure > System Settings
> Display.
From the Main Menu screen, select Settings > System Settings > Display.
2. Select a Menu Access setting and save your changes.
3. If you select Enable with PIN, you also need to type in a PIN and save your
changes.
Access the Printer Web Page
4. Open a browser window on your PC.
5. In the location or address bar, type the printer IP address and press Enter.
The printer web page appears.
6. Click Login. The login page appears.
Menu Access
Setting
Description
Enable (default) All users can access the menus from the Main
Menu and from the USB flash drive menu.
Enable with PIN Users need to enter a PIN to access the Main
Menu or USB flash drive menu.
Disable Users cannot access the menus from the Main
Menu or from the USB flash drive menu.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honeywell PD45 and is the answer not in the manual?

Honeywell PD45 Specifications

General IconGeneral
Print TechnologyDirect Thermal / Thermal Transfer
Ribbon Core1 inch (25.4 mm)
Print Resolution203 dpi
Max Print Width4.25 inches (108 mm)
Max Print Speed8 ips (203 mm/s)
ConnectivityUSB 2.0, RS-232, Ethernet
Media HandlingLabel gap, label black mark
Media Thickness0.0025 inch to 0.01 inch (0.0635 mm to 0.254 mm)
Ribbon Width1 inch to 4.33 inches (25.4 mm to 110 mm)
Ribbon Length984 feet (300 meters)
Operating Temperature5°C to 40°C (41°F to 104°F)
Power Requirements100-240 VAC, 50/60 Hz
Media Width25.4 mm (1 in) to 118 mm (4.65 in)
