Honeywell PD45 User Manual

72 PD45 User Guide
Clip Default Determines if the printer prints items outside the
printable area of the label.
When this is set to Off, the printer returns an error if any
part of a barcode label cannot be printed because that
part extends beyond the printable area. When this is set
to On, the printer prints all barcode labels, but may also
print unreadable, incomplete labels.
Off
Print Mode Selects the printer tear off, peel off, or rewind media
mode
Tear Off
Peel Strength Selects strength the printer uses to peel the label off
from liner. Use Medium or High if the printer has trouble
to peel certain types of media.
Low
Label Top Adjust Sets the length of media the printer feeds (positive
value) or retracts (negative value) before printing a label.
Unit of measurement is defined in the Unit of Measure
parameter. Range is -9999 to +9999.
0
Label Reset
Adjust
Sets the length of media the printer feeds (positive
value) or retracts (negative value) after printing a label.
Unit of measurement is defined in the Unit of Measure
parameter. Range is -9999 to +9999.
0
Media Calibration
Mode
Selects the mode the printer uses to calibrate media. Use
Slow if the printer has trouble identifying gaps or marks
in media. Use Fast with Retraction or Slow with
Retraction to retract the media and ribbon fed for
calibration back to the printer.
Slow
Length (Slow
Mode)
If Media Calibration Mode is set to Slow, the printer
prints the media length plus 10 mm. This value sets an
additional amount of media to be printed. Unit of
measurement is defined in the Unit of Measurement
parameter. Range is 0 to 3200.
0
Sensor Sensitivity
Level
Sets the sensitivity of the sensor. 0
Power Up Action Sets the action when you turn the printer on:
No Action
Form feed: The printer feeds one label.
Test feed: The printer prints two configuration labels as
it calibrates the media sensors.
Smart Calibration: Detects media type (gap, black mark,
or continuous, detects printing method (ribbon or no-
ribbon), and calibrates media length.
Smart Calibration
Head Down
Action
Sets the action when you close the print mechanism
after opening it:
No Action
Form feed: The printer feeds one label.
Test feed: The printer prints two configuration labels as
it calibrates the media sensors.
Smart Calibration: Detects media type (gap, black mark,
or continuous, detects printing method (ribbon or no-
ribbon), and calibrates media length.
Smart Calibration
Media Setting Description Default

Honeywell PD45 Specifications

General

Print Technology	Direct Thermal / Thermal Transfer
Ribbon Core	1 inch (25.4 mm)
Print Resolution	203 dpi
Max Print Width	4.25 inches (108 mm)
Max Print Speed	8 ips (203 mm/s)
Connectivity	USB 2.0, RS-232, Ethernet
Media Handling	Label gap, label black mark
Media Thickness	0.0025 inch to 0.01 inch (0.0635 mm to 0.254 mm)
Ribbon Width	1 inch to 4.33 inches (25.4 mm to 110 mm)
Ribbon Length	984 feet (300 meters)
Operating Temperature	5°C to 40°C (41°F to 104°F)
Power Requirements	100-240 VAC, 50/60 Hz
Media Width	25.4 mm (1 in) to 118 mm (4.65 in)
