128 | Performance Series DVR User Guide
www.honeywellvideo.com
Connections
Video Input 4/8/16, BNC 1 Vp-p @ 75 ohms
Video Output 1 - Composite main monitor,
BNC 1 Vp-p @ 75 ohms
1 - VGA Main Monitor
1 - Spot BNC 1 Vp-p @ 75 ohms
Audio Input/Output Input: 4 channel, line level
Output: 1 channel, line level
Sensor Inputs General
Purpose
4 inputs (4ch) – terminal block
8 inputs (8ch) – terminal block
16 inputs (16ch) – terminal block
Control Outputs 1 – relay out (4ch); NC/NO terminal block
4 – relay out (8 & 16ch); NC/NO terminal block
Serial Ports 2 – USB (2.0) ports: one on the front panel and another on the
rear panel
1 – RS485 terminal block
1 – RS232
Primary Storage SATA HDD
Networking RJ45 10M/100M self-adaptive Ethernet interface
Electrical
Input Voltage 12 V DC power adapter
Power Consumption HRG4 and HRG8 25 W (max)
HRG16 30 W (max)
Mechanical
Dimensions (W x D x H) 4ch unit: 12.4 × 9.1 × 1.8 in. (315 × 230 × 45 mm)
8/16ch unit: 17.5 × 11.4 × 1.8 in. (445 × 290 × 45 mm)
Weight HRG4 5.7 lbs (2.6 kg)
HRG8 and HRG16 10.1 lbs (4.6 kg)
Construction Housing: Steel chassis
Environmental
Temperature Operating: 32°F to 104°F (0°C to 55°C)
Storage: –22°F to 176°F (–30°C to 80°C)
Relative Humidity 10% to 90%, non-condensing
Regulatory
Emissions FCC Part 15B, Class A
Immunity EN50130-4:1995+A1:1998+A2:2003
Safety CSA/UL 60950-1, 2nd Edition
Specifications
