800-12005V1 - A - 08/2012

Specifications | 129

Dimensions

LINE IN

AUDIO OUT

RS-232

VGA

LAN

HDMI

ALARM IN

RS-485 ALARM OUT

12V

POWER

LOOP O UT

AUD IO INVIDEO O UT VIDEO I N

HRG4

HRG8 and HRG16 (HRG16 shown)

12.4" (315 mm)

9.1" (230 mm)

17.5" (455 mm)

11.4" (290 mm)

1.8"

(45 mm)

1.8"

(45 mm)

1.8"

(45 mm)

1.8"

(45 mm)
