74 | Performance Series DVR User Guide
www.honeywellvideo.com
Figure 7-10 Alarm Input Handle Menu
5. Select the Triggered Camera tab.
6. Select cameras to trigger for recording when an alarm occurs by selecting the check
boxes under the desired cameras (see Figure 7-10).
You can select a PTZ camera to link with the alarm input and then set the call up of preset,
patrol, and pattern for alarm-linked actions.
7. Click OK to save the settings.
8. You can now add a schedule to start recording when an alarm is triggered (see
Scheduling Recording on page 41).
Alarm outputs can also be configured in the Alarm Settings menu.
To set up an Alarm Output:
1. Select the Alarm Output tab to enter the Alarm Output interface (see Figure 7-11).
Figure 7-11 Alarm Output Interface
2. Select the output you want to configure, and then click Set to enter the settings page for
the selected channel (see Figure 7-12).
