Honeywell Solaris 7980g User Manual

Solaris 7980g User Guide 207
Pixel Depth - 1 bit/pixel (B&W) IMGBPP1 162
*Don’t Sharpen Edges IMGEDG0 163
Sharpen Edges (0-23) IMGEDG## 163
*File Format - JPEG IMGFMT6 164
File Format - KIM IMGFMT0 164
File Format - TIFF binary IMGFMT1 164
File Format - TIFF binary group 4,
compressed
IMGFMT2 164
File Format - TIFF grayscale IMGFMT3 164
File Format - Uncompressed binary IMGFMT4 164
File Format - Uncompressed grayscale IMGFMT5 164
File Format - BMP IMGFMT8 164
*Histogram Stretch Off IMGHIS0 164
Histogram Stretch On IMGHIS1 164
*Noise Reduction Off IMGFSP0 165
Noise Reduction On IMGFSP1 165
Invert Image around X axis IMGNVX1 165
Invert Image around Y axis IMGNVY1 165
Rotate Image none IMGROT0 166
Rotate Image 90° right IMGROT1 166
Rotate Image 180° right IMGROT2 166
Rotate Image 90° left IMGROT3 166
JPEG Image Quality (0-100) *50 IMGJQF### 166
*Gamma Correction Off IMGGAM0 167
Gamma Correction On (0-1000) IMGGAM### 167
Image Crop - Left (0-843) *0 IMGWNL### 167
Image Crop - Right (0-843) *843 IMGWNR### 167
Image Crop - Top (0-639) *0 IMGWNT### 167
Image Crop - Bottom (0-639) *639 IMGWNB### 168
Image Crop - Margin (1-238) *0 IMGMAR### 168
Protocol - None (raw) IMGXFR0 168
Protocol - None (default USB) IMGXFR2 168
Protocol - Hmodem Compressed IMGXFR3 168
Protocol - Hmodem IMGXFR4 168
Ship Every Pixel IMGSUB1 169
Ship Every 2nd Pixel IMGSUB2 169
Ship Every 3rd Pixel IMGSUB3 169
*Document Image Filter Off IMGUSH0 169
Selection
Setting
* Indicates default
Serial Command
# Indicates a numeric
entry
Page

Honeywell Solaris 7980g Specifications

General

Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power consumption	400 mA
Power source type	AC
AC adapter output voltage	5 - 5.2 V
USB version	2.0
Standard interfaces	Keyboard wedge, RS-232, USB
USB 2.0 ports quantity	1
Connectivity technology	Wired
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	CE, RoHS
Product color	Black
LED indicators	Status
Housing material	-
Programming function	Yes
International Protection (IP) code	IPX5
Sustainability certificates	RoHS
Type	Fixed bar code reader
Scanner type	1D/2D
Maximum scan area	0 x 190 mm
Yaw reading angle	-75 - 75 °
Pitch reading angle	-65 - 65 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 32, Code 39, Code 93, EAN-13, EAN-8, Intelligent Mail, JAN, MSI, PLANET, POSTNET, Plessey, Telepen, Trioptic, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Codablock, Code 49, Data Matrix, Han Xin, MaxiCode, Micro QR Code, PDF417, QR Code
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	85 mm
Width	152 mm
Height	148 mm
Weight	539 g
