38 UDA2182 Communications User Guide January 09
12. Web Pages
12.1 Overview
The UDA has web browsing capability. With a web browser, such as Internet Explorer, you can view
many of the operating parameters of the UDA. Configuration of the Ethernet parameters is also provided
using a web browser.
To view web pages:
1. Connect a PC to the UDA. A static or a dynamic IP address can be assigned to the UDA using the
communication menu from the front panel. (Table 3-1 Configurable Parameters)
2. On the UDA’s front-panel, go to the Comm status display menu and record the IP address.
3. On the PC connected to the UDA, start up a web browser such as Internet Explorer 6 and above.
4. To browse the web pages, type the IP address into the address bar of Internet explorer and press
enter. After a few seconds, the UDA login screen should appear.
Following sections explains various web pages that can be browsed.
12.2 Login Page
Login page is displayed when the UDA is browsed from Internet Explorer using the IP address assigned to
it. The page is displayed as shown below:
Figure 12-1 Login Page
