UDA Communications Setup
6 UDA2182 Communications User Guide January 09
3.1.2 Setting up a Static IP Address using the Front Panel
Be sure you have an IP address that allows it to be accessible on the intended Ethernet network. Consult
your IT department or network administrator for allocating IP addresses to the UDAs as required.
You will need to set each UDA’s IP address prior to network connection since every UDA is shipped with
the default IP address of 192.168.1.254. Placing multiple UDAs on the same network before they have
been given unique IP addresses will cause problems.
Table 3-2 Setting Up a Static Address
Step Action
1 On the front panel, select the Communication menu option in the Setup menu.
Setup
Inputs
Relays
Outputs
Maintenance
Alarms
Logic
PID Control
Math
Communication
Monitors
Auxiliary
Auto Cycling
Setup
Relays
Outputs
Maintenance
Alarms
Logic
PID Control*
Math
Communication
Monitors
Auxiliary
Auto Cycling*
Setup
Relays
Outputs
Maintenance
Alarms
Logic
PID Control
Math
Communication
Monitors
Auxiliary
Auto Cycling
Setup
Relays
Alarms
Logic
PID Control*
Math
Monitors
Auxiliary
Auto Cycling*
Variables
Setup
Inputs
Relays
Outputs
Maintenance
Alarms
Logic
PID Control
Math
Communication
Monitors
Auxiliary
Auto Cycling
Setup
Relays
Outputs
Maintenance
Alarms
Logic
PID Control*
Math
Communication
Monitors
Auxiliary
Auto Cycling*
Setup
Relays
Outputs
Maintenance
Alarms
Logic
PID Control
Math
Communication
Monitors
Auxiliary
Auto Cycling
Setup
Relays
Alarms
Logic
PID Control*
Math
Monitors
Auxiliary
Auto Cycling*
Variables
2 In the Communication menu, select Ethernet.
COMMUNICATION
RS485
Ethernet
IR FrontPanel
Modbus
COMMUNICATION
RS485
Ethernet
IR FrontPanel
Modbus
You will see the following Parameters:
Port Reset
DHCP (Dynamic Host Configuration Protocol)
IP Addr Octet 1-4 (IP Address)
SbntMsk Octet 1-4 (Subnet Mask)
Dflt Gtwy Octet 1-4 (Default Gateway)
DNS Srvr Octet 1-4 (Domain Name Service)
3
Set DHCP to No.
4
Set the IP Addr octets 1 through 4 to the IP address where octet 1 is the left-most IP
address octet and octet 4 is the right-most IP address octet. For example, for the default
address of 192.168.1.254, octet 1 equals 192, octet 2 equals 168, octet 3 equals 1, and
octet 4 equals 254.
5
Set the subnet mask octets 1 through 4.
6
Set the Default gateway octets 1 through 4.
7 If you are not using a DNS server to identify your email server’s address, you can leave the
