Honeywell XENON 1900 User Manual

12 - 3
*Storage outside of this temperature range could be detrimental to battery life.
Granit 1910i Industrial Corded Scanner Product
Specifications
Expected Hours of Operation 14
Expected Charge Time 4.5 hours
Radio:
Frequency
2.4 to 2.5 GHz (ISM Band) Frequency Hopping
Bluetooth v.2.1
Range
33 ft. (10 m) typical
Data Rate
Up to 1 MBps
Temperature Ranges:
Operating
32° F to +122° F (0° C to 50° C)
Storage*
-40°F to +158°F (-40°C to 70°C)
Humidity Up to 95% non-condensing
Mechanical Drop
Operational after 50 drops from 6 feet
(1.8 m) to concrete
Vibration Withstands 5G peak from 22 to 300 Hz
ESD Sensitivity
Up to 15kV direct air
Up to 8 kV indirect coupling plane
Sealant Rating IP41
Parameter Specification
Dimensions (Typical):
Height
7.7 in. (19.45cm)
Length
5.2 in. (13.31cm)
Width
2.9 in. (7.5cm)
Weight
10.6 oz. (300g)
Illumination LED:
Peak Wavelength
656nm (hyper red LED)
IEC 62471: “Exempt Risk Group”
Aiming:
Peak Wavelength Laser
650nm
IEC 60825-1: “Class 2”
Optical Power Laser
<1mW
Image Size 838 x 640 pixels
Skew Angle +
65°
Parameter Specification

Honeywell XENON 1900 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Scanner type	1D/2D
Pitch reading angle	-45 - 45 °
Linear (1D) barcodes supported	-
Standard interfaces	USB, Keyboard wedge, RS-232, RS-485
Connectivity technology	Wired
Input voltage	4 - 5.5 V
Power consumption	450 mA
Power source type	DC
Power consumption (standby)	0.45 W
Power consumption (typical)	2.3 W
Shockproof	Yes
Product color	Black
International Protection (IP) code	IP41
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Sustainability certificates	RoHS

Weight and Dimensions

Depth	104 mm
Width	71 mm
Height	160 mm
Weight	147 g
