3 - 11
Paging Pitch
When you press the Page button on the base or Access Point, the scan-
ners associated with that base or Access Point will begin beeping (see
Page Button on page 3-5). You can set the pitch of the paging beep for
each scanner by scanning one of the following bar codes.
Default = Low.
Error Indicators
Beeper Pitch - Base Error
Note: This feature only applies to the CCB01-010BT base.
The CCB01-010BT base can be configured to beep at a particular pitch
when an error occurs, such as transmission problems to a host system.
The beeper pitch codes modify the pitch (frequency) of the error tone the
base emits when there is an error.
Default = Low.
Number of Beeps - Base Error
Note: This feature only applies to the CCB01-010BT base.
* Low (1000 Hz)
Medium (3250 Hz)
High (4200 Hz)
* Razz (250 Hz)
Medium (3250 Hz)
High (4200 Hz)

Honeywell XENON 1900 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Scanner type	1D/2D
Pitch reading angle	-45 - 45 °
Linear (1D) barcodes supported	-
Standard interfaces	USB, Keyboard wedge, RS-232, RS-485
Connectivity technology	Wired
Input voltage	4 - 5.5 V
Power consumption	450 mA
Power source type	DC
Power consumption (standby)	0.45 W
Power consumption (typical)	2.3 W
Shockproof	Yes
Product color	Black
International Protection (IP) code	IP41
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Sustainability certificates	RoHS

Weight and Dimensions

Depth	104 mm
Width	71 mm
Height	160 mm
Weight	147 g
