49
48.MENU M3 - Language selection
Allows the user to set the language from among those available.
Procedure for choosing the language
Press P3 for a few seconds or wait until it returns to the home screen
49.Menu M4 - Stand-by
Enables or disables Stand-by mode. OFF and vice versa. The mode is off in the factory settings
Procedure for programming the Stand-by function
Press P3 for a few seconds or wait until it returns to the home screen
50.MENU M5 - Buzzer
Lets the user enable or disable the controller buzzer during Alarms.
Procedure for programming the buzzer function
Press P3 for a few second or wait until it returns to the home screen
51.MENU M6 - First load
This function is only available when the stove is OFF and lets the screw feeder be loaded at the first stove startup when the
pellet tank is empty. (Fill the pellet tank and follow the procedure below. Based on the pellet characteristics, it may be
necessary to repeat the procedure until the fuel drops into the brazier. Before ignition, remove the pellets that already dropped
into the brazier.)
Procedure for programming the first fill.
Wait for the system to start and stay until the time indicated on the display is over or until the P3 button is pressed.
52.MENU M7 - Stove status
In the M7 menu after pressing P3, the status of certain variables during stove operation will scroll. The table below shows an
example of the display and the meaning of these values.
Procedure for programming the stove status function
The system provides information on:
1) Screw feeder pellet loader status 2) Time out 3) Room thermostat 4) Smoke temperature 5) Smoke exhaust speed
Press P3 for a few second or wait until it returns to the home screen
