Removal and Replacement Procedures
6. Unlatch the socket locking lever (1).
7. Lift the processor from the socket (2).
Figure 2-40: Unlocking and removing a processor
CAUTION: Always use a new heatsink when replacing processors. Failure to use new
components may result in damage to the processor.
CAUTION: Make sure the processor locking lever is open before inserting the processor into
the processor socket. Attempting to insert the processor with the processor locking lever
closed may result in damage to the processor.
2-36 HP ProLiant DL360 Generation 3 Server Maintenance and Service Guide
