Cable Connections
System board connectors are color-coded to make it easier to find the proper connection.
Cable To Cable Designator
Power Supply Main power, 24-pin P1
Power Supply CPU power, 4-pin P2
Power Supply SATA Hard drive P3
Power Supply SATA Optical drive P4
Connector Name Connector Color Description
F_PANEL Black Front LED/Power cable
SPEAKER White Speaker cable
FLOPPY Black Diskette drive
F_AUDIO Yellow Front audio cable
F_USB1 White Front I/O USB cable
SATA0 Blue Primary hard drive data cable
SATA4 Red Optical drive data cable
CPU FAN White Heatsink fan cable
F_USB2 Black Media card reader cable
96 Chapter 8 Removal and Replacement Procedures Small Form Factor (SFF) Chassis

HP dx7500 - Microtower PC Specifications

General

Memory	Up to 8 GB DDR2 SDRAM
Form Factor	Microtower
Power Supply	300W
Processor	Intel Core 2 Duo, Intel Pentium Dual-Core, Intel Celeron
Storage	SATA hard drives up to 500 GB
Optical Drive	DVD-ROM or DVD+/-RW
Graphics	Integrated Intel Graphics Media Accelerator 3100, Optional discrete graphics cards
Audio	Integrated High Definition Audio
Network	Integrated Gigabit Ethernet
Expansion Slots	1 PCI Express x16, 2 PCI Express x1, 1 PCI
Ports	USB 2.0, serial, parallel, VGA, audio in/out
Operating System	Windows Vista Business, Windows XP Professional, FreeDOS
Weight	Approx. 22 lbs (10 kg)
