HP dx7500 - Microtower PC User Manual

Cable Connections
System board connectors are color-coded to make it easier to find the proper connection.
Connector Name Connector Color Description
ATXPOWER White Power supply, 24-pin
ATX_CPU White Power supply, 4-pin
FLOPPY Black Diskette drive
CHASSIS_FAN1 Brown Chassis fan
CPU FAN White Heatsink fan
F_PANEL Black Front power button/LED
F_USB1 White Front I/O USB cable
F_AUDIO Yellow Front I/O audio
SPEAKER White Internal speaker
F_1394 Red Serial port
F_USB2 Black Media card reader
SATA0 dark blue Primary hard drive
SATA1 white Primary optical drive
SATA4 red Second hard drive
SATA5 black Second optical drive
Cable Management 61

HP dx7500 - Microtower PC Specifications

General

Memory	Up to 8 GB DDR2 SDRAM
Form Factor	Microtower
Power Supply	300W
Processor	Intel Core 2 Duo, Intel Pentium Dual-Core, Intel Celeron
Storage	SATA hard drives up to 500 GB
Optical Drive	DVD-ROM or DVD+/-RW
Graphics	Integrated Intel Graphics Media Accelerator 3100, Optional discrete graphics cards
Audio	Integrated High Definition Audio
Network	Integrated Gigabit Ethernet
Expansion Slots	1 PCI Express x16, 2 PCI Express x1, 1 PCI
Ports	USB 2.0, serial, parallel, VGA, audio in/out
Operating System	Windows Vista Business, Windows XP Professional, FreeDOS
Weight	Approx. 22 lbs (10 kg)
