HP dx7500 - Microtower PC - Page 112

6. Remove the two retainer screws that secure the drive to the bay (1) then slide the drive forward
and out of the bay (2).
Figure 8-9 Removing a 5.25” External Drive
NOTE: To install an optical drive, refer to Installing an Optical Drive into the 5.25-inch Drive Bay
on page 103.
102 Chapter 8 Removal and Replacement Procedures Small Form Factor (SFF) Chassis
