HP E14 G4 User Manual

b. Pivot the monitor clockwise or counterclockwise 90° from landscape to portrait orientation (2).
IMPORTANT: If the monitor is not in full height and full tilt position when pivoting, the bottom
right corner of the monitor panel will come in contact with the base and potentially cause damage
to the monitor.
If you are adding an optional speaker bar to the monitor, install it after pivoting the monitor. The
speaker bar will come in contact with the base when the monitor pivots and potentially cause
damage to the monitor or speaker bar.
NOTE: Use the operating system's display settings to rotate the image on the screen from
portrait to landscape. To rotate the OSD from portrait to landscape, open the OSD menu and select
Image Adjustment, select On-Screen Menu Rotation, and then select Portrait.
Installing a security cable
Use the key that came with the optional security cable to attach and remove the lock.
Turning on the monitor
This section provides important information about preventing damage to your monitor, startup indicators,
and troubleshooting information.
Setting up the monitor 15

HP E14 G4 Specifications

General

Color gamut	72 %
Pixel pitch	0.161 x 0.161 mm
Screen shape	Flat
Pixel density	157 ppi
Display diagonal	14 \
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	59 - 60 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 80 kHz
Contrast ratio (typical)	800:1
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
Built-in USB hub	Yes
DisplayPorts quantity	0
USB upstream port type	USB Type-C
Power consumption (standby)	0.3 W
Power consumption (typical)	6 W
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	61 mm
Package width	405 mm
Package height	284 mm
Package weight	1540 g
Tilt angle range	0 - 78 °
Certification	BIS; BSMI; CB; CCC; CE; cTUVus; EAC; ENERGY STAR®; FCC; ICES; ISE for Cambodia; ISO 9241-307; KC/KCC; NOM; SEPA; Taiwan Green Mark; TUV/GS; VCCI; Vietnam MEPS; WEEE; ISC; WW application; UAE
Product color	White
Market positioning	Business

Weight and Dimensions

Depth (with stand)	15.2 mm
Width (with stand)	321.4 mm
Height (with stand)	210 mm
Weight (with stand)	640 g
