Button lockouts
The button lockout function is available only when the monitor is on, an active signal is displayed, and the
OSD menu is closed. Holding down the power button or Menu button for 10 seconds disables that button. You
can re-enable the button by holding it down again for 10 seconds.
Optimizing image performance (analog input)
If you would like to customize your settings, this section describes how to manually optimize your monitor's
image.
You can adjust two controls in the on-screen display to improve image performance: Clock and Phase
(available in the OSD menu). Use these controls only when the auto-adjustment function does not provide a
satisfactory image.
NOTE: You can adjust the Clock and Phase controls only when you use an analog (VGA) input. These controls
are not adjustable for digital inputs.
The Clock must rst be set correctly because the Phase settings are dependent on the main Clock setting.
Clock—Increases or decreases the value to minimize any vertical bars or stripes visible on the screen
background.
Phase—Increases or decreases the value to minimize video ickering or blurring.
NOTE: When you use the controls, you will obtain the best results by using the auto-adjustment pattern
software utility. You can download this utility from http://www.hp.com/support.
When adjusting the Clock and Phase values, if the monitor images become distorted, continue adjusting the
values until the distortion disappears. To restore the factory settings, press the Menu button to open the OSD
menu, then select Management, select Factory Reset, and select Yes.
To eliminate vertical bars (Clock):
1. Press the Menu button to open the OSD menu, select Image, and then select Clock and Phase.
2. Select Clock, and then use the OSD buttons on the monitor that display up and down arrow icons to
eliminate vertical bars. Press the buttons slowly so that you do not miss the optimum adjustment point.
3. After adjusting the Clock, if ickering, blurring, or bars appear on the screen, proceed to adjust the
Phase.
To remove ickering or blurring (Phase):
1. Press the Menu button to open the OSD menu, select Image, and then select Clock and Phase.
24 Chapter 3 Support and troubleshooting

Table of Contents

Other manuals for HP E14 G4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP E14 G4 and is the answer not in the manual?

HP E14 G4 Specifications

General IconGeneral
Color gamut72 %
Pixel pitch0.161 x 0.161 mm
Screen shapeFlat
Pixel density157 ppi
Display diagonal14 \
Display technologyLED
Native aspect ratio16:9
Vertical scan range59 - 60 Hz
Maximum refresh rate60 Hz
Horizontal scan range30 - 80 kHz
Contrast ratio (typical)800:1
Display brightness (typical)400 cd/m²
Supported graphics resolutions640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
Built-in USB hubYes
DisplayPorts quantity0
USB upstream port typeUSB Type-C
Power consumption (standby)0.3 W
Power consumption (typical)6 W
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)20 - 80 %
Package depth61 mm
Package width405 mm
Package height284 mm
Package weight1540 g
Tilt angle range0 - 78 °
CertificationBIS; BSMI; CB; CCC; CE; cTUVus; EAC; ENERGY STAR®; FCC; ICES; ISE for Cambodia; ISO 9241-307; KC/KCC; NOM; SEPA; Taiwan Green Mark; TUV/GS; VCCI; Vietnam MEPS; WEEE; ISC; WW application; UAE
Product colorWhite
Market positioningBusiness
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)15.2 mm
Width (with stand)321.4 mm
Height (with stand)210 mm
Weight (with stand)640 g
