Table 2-2 Button names and descriptions
Button Description
(1) Menu button Opens the OSD main menu, selects a menu item from the OSD, or closes the OSD
menu.
(2) Brightness button
Assignable function button
Adjusts the monitor screen brightness.
(3) Color button
Assignable function button
Opens the Color menu where you can adjust the screen color.
(4) Next Input button
Assignable function button
Switches the monitor’s input source to the next active input.
Reassigning the function buttons
Except for the Menu button, you can change the action associated with a function button from the default
action that you can quickly access your most commonly used menu items.
To reassign the function buttons:
1. Press the Menu button to open the OSD menu.
2. Select Menu, select Assign Buttons, and then select one of the available options for the button that you
want to assign.
Changing the Power Mode setting (select products only)
This section describes how to activate Performance mode. Certain features on your monitor might require
Performance mode to be active.
When in sleep mode, to comply with international power standards, the monitor default setting is Power
Saver mode.
If your monitor supports Performance mode, then to keep the USB ports enabled when the monitor is in Auto-
Sleep Mode, change the Power Mode setting from Power Saver to Performance.
NOTE: If you are connecting a computer that is not battery powered, the Power Mode setting must be
changed to Performance mode.
To change the power mode setting:
1. Press the Menu button to open the OSD menu.
2. Select Power, select Power Mode, and then select Performance.
3. Select Back and close the OSD.
Using Auto-Sleep Mode (select products only)
Your monitor has an energy-saving feature called Auto-Sleep Mode, a reduced power state. This section
describes how to activate or adjust Auto-Sleep Mode on your monitor.
When Auto-Sleep Mode is enabled (enabled by default), the monitor enters a reduced power state when the
computer signals low power mode (absence of either horizontal or vertical sync signal).
20 Chapter 2 Using the monitor

Table of Contents

Other manuals for HP E14 G4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP E14 G4 and is the answer not in the manual?

HP E14 G4 Specifications

General IconGeneral
Color gamut72 %
Pixel pitch0.161 x 0.161 mm
Screen shapeFlat
Pixel density157 ppi
Display diagonal14 \
Display technologyLED
Native aspect ratio16:9
Vertical scan range59 - 60 Hz
Maximum refresh rate60 Hz
Horizontal scan range30 - 80 kHz
Contrast ratio (typical)800:1
Display brightness (typical)400 cd/m²
Supported graphics resolutions640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
Built-in USB hubYes
DisplayPorts quantity0
USB upstream port typeUSB Type-C
Power consumption (standby)0.3 W
Power consumption (typical)6 W
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)20 - 80 %
Package depth61 mm
Package width405 mm
Package height284 mm
Package weight1540 g
Tilt angle range0 - 78 °
CertificationBIS; BSMI; CB; CCC; CE; cTUVus; EAC; ENERGY STAR®; FCC; ICES; ISE for Cambodia; ISO 9241-307; KC/KCC; NOM; SEPA; Taiwan Green Mark; TUV/GS; VCCI; Vietnam MEPS; WEEE; ISC; WW application; UAE
Product colorWhite
Market positioningBusiness
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)15.2 mm
Width (with stand)321.4 mm
Height (with stand)210 mm
Weight (with stand)640 g
