HP E14 G4 User Manual

1. Be sure that USB Type-C is your primary video input.
2. Add a second monitor by connecting a DisplayPort cable between the DisplayPort OUT port on the
primary monitor and the DisplayPort IN port on a secondary monitor.
NOTE: Three of the four daisy-chained monitors need to have DisplayPort IN and OUT video ports. The
last monitor in the chain needs only a DisplayPort IN video port.
3. Set a connected monitor to display the same image as the primary monitor or a dierent image.
DisplayPort 1.2 is the default setting, but the setting automatically changes to DisplayPort 1.2 when
DisplayPort OUT is connected to the secondary monitor.
4. To connect additional monitors (up to four maximum), press the Menu button to open the OSD menu.
Navigate to the USB Type-C conguration and select USB-C Video+USB2.0.
NOTE: All but the nal monitor in the chain must support DisplayPort multistreaming.
5. Connect the DisplayPort cable from the DisplayPort OUT port of one monitor to the DisplayPort IN port
of the next monitor.
22 Chapter 2 Using the monitor

HP E14 G4 Specifications

General

Color gamut	72 %
Pixel pitch	0.161 x 0.161 mm
Screen shape	Flat
Pixel density	157 ppi
Display diagonal	14 \
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	59 - 60 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 80 kHz
Contrast ratio (typical)	800:1
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
Built-in USB hub	Yes
DisplayPorts quantity	0
USB upstream port type	USB Type-C
Power consumption (standby)	0.3 W
Power consumption (typical)	6 W
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	61 mm
Package width	405 mm
Package height	284 mm
Package weight	1540 g
Tilt angle range	0 - 78 °
Certification	BIS; BSMI; CB; CCC; CE; cTUVus; EAC; ENERGY STAR®; FCC; ICES; ISE for Cambodia; ISO 9241-307; KC/KCC; NOM; SEPA; Taiwan Green Mark; TUV/GS; VCCI; Vietnam MEPS; WEEE; ISC; WW application; UAE
Product color	White
Market positioning	Business

Weight and Dimensions

Depth (with stand)	15.2 mm
Width (with stand)	321.4 mm
Height (with stand)	210 mm
Weight (with stand)	640 g
