HP Elite x2 G4 Tablet Service Manual

(13) Hall eect board cable
(14) Speaker cable
2. On models with a SIM card installed, remove the SIM tray.
NOTE: If a SIM blank is installed, you must remove it after removing the system board.
3. Peel the two strips of tape o the heat sink and from near the WWAN module (1).
4. Peel the WLAN antennas o the heat sink (2).
IMPORTANT: Use extreme care when peeling up the WLAN antennas. Keep them as at (not wrinkled)
as possible.
5. Remove the three Phillips M1.0 × 1.6 screws (3).
Component replacement procedures 61

HP Elite x2 G4 Tablet Specifications

General

Operating System	Windows 10 Pro
Battery Life	Up to 10 hours
Graphics	Intel UHD Graphics 620
Camera	5MP front-facing, 8MP rear-facing
Processor	Intel Core i5 or i7 (8th Gen)
RAM	Up to 16GB LPDDR3
Storage	Up to 1TB PCIe NVMe SSD
Weight	0.82 kg (tablet only)
Ports	2 x USB-C, 1 x USB-A, 1 x headphone/microphone combo
Wireless	Bluetooth 5
Audio	Bang & Olufsen, dual speakers
Battery	47 Wh Li-ion polymer
Dimensions	0.35 in
