Mounting the monitor head
The monitor head can be attached to a wall, swing arm, or other mounting xture.
IMPORTANT: This monitor supports the VESA® industry-standard 100 mm mounting holes. To attach a
third-party mounting solution to the monitor, use four 4 mm, 0.7 pitch, 10 mm–long screws. Longer screws
might damage the monitor. Verify that the manufacturers mounting solution is compliant with the VESA
standard and is rated to support the weight of the monitor head. For best performance, use the power and
video cables provided with the monitor.
NOTE: This apparatus is intended to be supported by a UL-listed or CSA-listed wall-mount bracket.
Removing the monitor stand
IMPORTANT: Before disassembling the monitor, be sure that the monitor is turned o and all cables are
disconnected.
1. Disconnect and remove all cables from the monitor.
2. Position the monitor facedown on a at surface covered by protective sheet made of foam or a clean,
dry cloth.
3. Push up on the latch near the bottom center of the stand’s mounting plate (1).
4. Swing the bottom of the stand up until the mounting plate clears the recess in the monitor head (2).
5. Slide the stand out of the recess (3).
Setting up the monitor 7
