Table A-4 68.6 cm (27 in) preset display resolutions
Preset Pixel format Horz freq (kHz) Vert freq (Hz)
(1) 640 × 480 31.469 59.940
(2) 720 × 400 31.469 70.087
(3) 800 × 600 37.879 60.317
(4) 1024 × 768 48.363 60.004
(5) 1280 × 720 45.000 60.000
(6) 1280 × 800 49.702 59.810
(7) 1280 × 1024 63.981 60.020
(8) 1440 × 900 55.935 59.887
(9) 1600 × 900 60.000 60.000
(10) 1680 × 1050 65.290 59.954
(11) 1920 × 1080 67.500 60.000
(12) 2560 × 1080 66.000 60.000
(13) 2560 × 1440 88.787 59.951
Table A-5 Preset timing resolutions
Preset Timing name Pixel format Horz freq (kHz) Vert freq (Hz)
(1) 480p 640 × 480 31.469 59.940
(2) 480p 720 × 480 31.469 59.940
(3) 720p60 1280 × 720 45.000 60.000
(4) 576p 720 × 576 31.250 50.000
(5) 720p50 1280 × 720 37.500 50.000
(6) 1080p60 1920 × 1080 67.500 60.000
(7) 1080p50 1920 × 1080 56.250 50.000
Entering user modes
Under the following conditions, the video controller signal may occasionally call for a mode that is not preset:
You are not using a standard graphics adapter.
You are not using a preset mode.
If this occurs, you may need to readjust the parameters of the monitor screen by using the on-screen display
menu. You can make changes to any or all of these modes and save them in memory. The monitor
automatically stores the new setting and then recognizes the new mode just as it does a preset mode. In
addition to the factory preset modes, there are at least 10 user modes that you can enter and store.
