– MicroSD card reader
– Headset jack
– Power connector
Mobility head unit features
To identify the mobility head unit features, use this illustration and table.
Table 2-1 Identifying the mobility head unit features
Features
1 Upward-facing laser barcode scanner* (optional) 12 Fingerprint reader (optional)
2 Power button 13 Barcode scanner button (optional)
3 Ambient light sensor 14 Contactless payment card scanner (optional)**
4 Camera light 15 Multi-charger connector (optional)
5 Camera 16 Downward-facing laser barcode scanner* (optional)
6 Infrared light 17 Docking connector (optional)
7 Volume up button 18 Near-eld communication (NFC)
8 Volume down button 19 Rear-facing camera light
9 SIM card door (optional) 20 Rear-facing camera
10 USB Type-C port 21 Payment card slot (optional)**
11 USB Type-C port
* The barcode scanner button is always active when the computer is docked or undocked.
**Only available in the US.
6 Chapter 2 Computer features
