Hardware options installation 64
5.
Remove the access panel (on page 18).
6. Remove the air baffle (on page 20).
CAUTION: Any attempt to remove an installed TPM from the system board breaks or
disfigures the TPM security rivet. Upon locating a broken or disfigured rivet on an installed
TPM, administrators should consider the system compromised and take appropriate measures
to ensure the integrity of the system data.
7. Install the TPM board. Press down on the connector to seat the board ("System board components"
on page 10).
8. Install the TPM security rivet by pressing the rivet firmly into the system board.
9. Install the air baffle (on page 19).
10. Install the access panel (on page 17).
11. Install the bezel (on page 16).
12. Return the server to an upright position.
13. Connect each power cord to the server.
14. Connect each power cord to the power source.
15. Power up the server (on page 16).
