Component identification 8
Rear panel components
1
NIC connector 1/ Shared iLO connector
PCIe slot 4, PCIe3 x16 (16,8,4,1), full-length*
PCIe slot 3, PCIe3 x4 (1), full-length*
PCIe slot 2, PCIe3 x4 (1), full-length*
PCIe slot 1, PCIe3 x8 (4,1), half-length*
10
* For more information on the expansion slot specifications, see "PCIe expansion slot definitions (on page 11)."
