Table 5-11 Country power supply settings (continued)
Japan 115W The United Kingdom 230W
Latin America 115W The United States 115W
System Board
When replacing the system board, be sure that the following components are removed from the
defective system board and installed on the replacement system board:
●
Memory modules
●
Processor
●
Expansion cards
To remove the system board:
1.
Prepare the computer for disassembly (
Preparation for Disassembly on page 42).
2.
Remove the access panel (
Access Panel on page 43).
3.
Lay the computer on its side with the rear facing toward you.
4.
Remove the front bezel (
Front Bezel on page 44).
5.
Remove an expansion cards (
Expansion Cards on page 54).
6.
Disconnect the power, and data cables from the back of all installed drives.
7.
Disconnect all cables from the system board.
8. Remove the eight screws that secure the system board to the chassis (1).
82 Chapter 5 Removal and Replacement Procedures Minitower (MT) Chassis
