Front Bezel
NOTE: Computer appearance may vary.
1.
Prepare the computer for disassembly (
Preparation for Disassembly on page 87).
2.
Remove the access panel (
Access Panel on page 88).
3. Lift up the three tabs on the side of the bezel (1), then rotate the bezel off the chassis (2).
Figure 6-2 Removing the Front Bezel
To install the front bezel, reverse the removal procedure.
Front Bezel
89
