HP Pro 2110 Small Form Factor User Manual

5. Disconnect the power cable (1), data cable (2), and eject cables (3) from the rear of the optical
drive.
Figure 6-23 Disconnecting the Optical Drive Cables
6.
Slide the drive out the front of the unit.
Figure 6-24 Removing the Optical Drive
NOTE: To replace the drive, reverse the removal procedure.
When installing an optical drive, slide it into the drive bay until it snaps into place.
Removing the Hard Drive
NOTE: The system does not support Parallel ATA (PATA) hard drives.
Before you remove the old hard drive, be sure to back up the data from the old hard drive so that you
can transfer the data to the new hard drive.
114 Chapter 6 Removal and Replacement Procedures Small Form Factor (SFF) Chassis

HP Pro 2110 Small Form Factor Specifications

General

Brand	HP
Model	Pro 2110 Small Form Factor
Category	Desktop
Language	English
