HP ProCurve 3500yl Series User Manual

Web and MAC Authentication
Client Status
Client Status
The table below shows the possible client status information that may be
reported by a Web-based or MAC-based ‘show... clients’ command.
Reported Status Available Network
Connection
Possible Explanations
authenticated Authorized VLAN Client authenticated. Remains
connected until logoff-period or
reauth-period expires.
authenticating Switch only Pending RADIUS request.
rejected-no vlan No network access 1. Invalid credentials supplied.
2. RADIUS Server difficulties. See log
file.
3. If unauth-vid is specified it cannot be
successfully applied to the port. An
authorized client on the port has
precedence.
rejected-unauth vlan Unauthorized VLAN only 1. Invalid credentials supplied.
2. RADIUS Server difficulties. See log
file.
timed out-no vlan No network access RADIUS request timed out. If unauth-
vid is specified it cannot be
successfully applied to the port. An
authorized client on the port has
precedence. Credentials resubmitted
after quiet-period expires.
timed out-unauth vlan Unauthorized VLAN only RADIUS request timed out. After the
quiet-period expires credentials are
resubmitted when client generates
traffic.
unauthenticated Switch only Waiting for user credentials.
4-29

HP ProCurve 3500yl Series Specifications

General

Model	HP ProCurve 3500yl Series
Switching Capacity	176 Gbps
Layer	Layer 3
Input Voltage	100-240 VAC
PoE	Available on some models
Management	Web, CLI, SNMP
Routing Protocol	RIP, OSPF, BGP
Remote Management Protocol	Telnet
Features	VLAN
Power Consumption Operational	Varies by model
Memory	256 MB
Power Supply	Internal
Security Features	802.1X, RADIUS, TACACS+
Ports	24 or 48 x 10/100/1000Base-T ports
