Traffic/Security Filters
Filter Types and Operation
This list shows the filter created
to block (drop) traffic from
source port 5 (workstation "X") to
destination port 7 (server "A").
Notice that the filter allows
traffic to move from source port
5 to all other destination ports.
Figure 9-3. The Filter for the Actions Shown in Figure 9-2
Named Source-Port Filters
You can specify named source-port filters that may be used on multiple ports
and port trunks. A port or port trunk can only have one source-port filter, but
by using this capability you can define a source-port filter once and apply it
to multiple ports and port trunks. This can make it easier to configure and
manage source-port filters on your switch. The commands to define,
configure, apply, and display the status of named source-port filters are
described below.
Operating Rules for Named Source-Port Filters
â– A port or port trunk may only have one source-port filter, named or
not named.
â– A named source-port filter can be applied to multiple ports or port
trunks.
â– Once a named source-port filter is defined, subsequent changes only
modify its action, they don’t replace it.
â– To change the named source-port filter used on a port or port trunk,
the current filter must first be removed, using the no filter source-port
named-filter <filter-name > command.
9-6
