HP ProCurve 3500yl Series User Manual

Virus Throttling
Basic Connection-Rate Filtering Configuration
Example of a Basic Connection-Rate Filtering Configuration
Server
Company
Intranet
VLAN 1
15.45.100.1
VLAN 10
15.45.200.1
5400zl Switch
Server
VLAN 15
15.45.300.1
Switch
Server
Server
Switch
Switch
A
B
C
D
E
H
F
G
B1
B2
B3
B9
B4
D1
D2
Figure 3-2. Sample Network
Basic Configuration. Suppose that in the sample network, the administra-
tor wanted to enable connection-rate filtering and configure the following
response to high connection-rate traffic on the switch:
■ Ports B1 - B3: Throttle traffic from the transmitting host(s).
■ Port B4: Respond with Notify-Only to identify the transmitting
host(s).
■ Ports B9, D1, and D2: Block traffic from the transmitting host(s).
Figure 3-3 illustrates the configuration steps and resulting startup-config file.
3-14

HP ProCurve 3500yl Series Specifications

General

Model	HP ProCurve 3500yl Series
Switching Capacity	176 Gbps
Layer	Layer 3
Input Voltage	100-240 VAC
PoE	Available on some models
Management	Web, CLI, SNMP
Routing Protocol	RIP, OSPF, BGP
Remote Management Protocol	Telnet
Features	VLAN
Power Consumption Operational	Varies by model
Memory	256 MB
Power Supply	Internal
Security Features	802.1X, RADIUS, TACACS+
Ports	24 or 48 x 10/100/1000Base-T ports
