HP ProCurve 5406zl Access Security Guide

Configuring Secure Shell (SSH)
Configuring the Switch for SSH Operation
[port < 1-65535 | default >]
The TCP port number for SSH connections (default:
22). Important: See “Note on Port Number” on page
7-17.
[timeout < 5 - 120 >]
The SSH login timeout value (default: 120 seconds).
[version <1 | 2 | 1-or-2 >
The version of SSH to accept connections from.
(default: 1-or-2)
The ip ssh key-size command affects only a per-session, internal server key the
switch creates, uses, and discards. This key is not accessible from the user
interface. The switch’s public (host) key is a separate, accessible key that is
always 896 bits.
Note on Port ProCurve recommends using the default TCP port number (22). However, you
Number
can use ip ssh port to specify any TCP port for SSH connections except those
reserved for other purposes. Examples of reserved IP ports are 23 (Telnet)
and 80 (http). Some other reserved TCP ports on the switch are 49, 80, 1506,
and 1513.
The switch uses these five settings internally for
transactions with clients. See the Note, below.
Enables SSH on the switch.
Lists the current SSH
configuration and status.
With SSH running, the switch allows one console
session and up to three other sessions (SSH and/or
Telnet). Web browser sessions are also allowed, but
do not appear in the show ip ssh listing.
Figure 7-10. Example of Enabling IP SSH and Listing the SSH Configuration and Status
7-17

HP ProCurve 5406zl Specifications

General

Product Name	HP ProCurve 5406zl
Category	Switch
Layer	Layer 3
Operating Temperature	32°F to 131°F (0°C to 55°C)
Operating Humidity	15% to 95% non-condensing
Management	SNMP, CLI
Power Supply	Redundant power supplies (optional)
Memory	128 MB flash, 512 MB SDRAM
