HP ProDesk 400 G7 SFF

Table 11-1 Troubleshooting steps for nonvolatile memory usage (continued)
Nonvolatile
memory type Amount (Size)
Does this
memory
store
customer
data?
Does this
memory
retain data
when power
is removed?
What is the
purpose of this
memory?
How is data entered into this
memory?
How is this memory write-
protected?
DIMM Serial
Presence Detect
(SPD) conguration
data
256 bytes per
memory
module, 128
bytes
programmable
(not customer
accessible)
No Yes Stores memory
module
information.
DIMM SPD is programmed by
the memory vendor.
Data cannot be written to
this memory when the
module is installed in a
computer. The specic
write-protection method
varies by memory vendor.
System BIOS 9 MB Yes Yes Stores system
BIOS code and
computer
conguration
data.
System BIOS code is
programmed at the factory.
Code is updated when the
system BIOS is updated.
Conguration data and
settings are entered using the
Computer Setup (BIOS) or a
custom utility.
NOTE: Writing data to
this ROM in an
inappropriate manner can
render the computer non-
functional.
A utility must be used for
writing data to this
memory and is available
on the HP website; go to
http://www.hp.com/
support. Select Find your
product, and then follow
the on-screen
instructions.
Intel Management
Engine Firmware
(present only in
select Elite or Z
models. For more
information, go to
http://www.hp.com/
support. Select
Identify your
product for
manuals and
specic product
information, and
then follow the on-
screen
instructions.)
1.5 MB or 7 MB Yes Yes Stores
Management
Engine Code,
Settings,
Provisioning
Data and iAMT
third-party data
store.
Management Engine Code is
programmed at the factory.
Code is updated via Intel
secure rmware update utility.
Unique Provisioning Data can
be entered at the factory or by
an administrator using the
Management Engine (MEBx)
setup utility. The third-party
data store contents can be
populated by a remote
management console or local
applications that have been
registered by an administrator
to have access to the space.
The Intel chipset is
congured to enforce
hardware protection to
block all direct read-write
access to this area. An
Intel utility must be used
for updating the rmware.
Only rmware updates
digitally signed by Intel
can be applied using this
utility.
Bluetooth ash
(select products
only)
2 megabits No Yes Stores
Bluetooth
conguration
and rmware.
Bluetooth ash is
programmed at the factory.
Tools for writing data to this
memory are not publicly
available but can be obtained
from the silicon vendor.
A utility must be used for
writing data to this
memory and is made
available through newer
versions of the driver
whenever the ash
requires an upgrade.
802.11 WLAN
EEPROM
4 kilobits to 8
kilobits
No Yes Stores
conguration
and calibration
data.
802.11 WLAN EEPROM is
programmed at the factory.
Tools for writing data to this
memory are not made public.
A utility must be used for
writing data to this
memory and is typically
not made available to the
public unless a rmware
upgrade is necessary to
address a unique issue.
116 Chapter 11 Statement of memory volatility ENWW
