2 Illustrated parts catalog
Use this information to determine the spare parts that are available for the computer.
NOTE: HP continually improves and changes product parts. For complete and current information about
supported parts for your computer, go to http://partsurfer.hp.com, select your country or region, and then follow
the on-screen instructions.
Computer major components
To identify the computer major components, use this illustration and table.
Table 2-1 Computer major components and their descriptions
Item Description
(1) Access panel
(2) Power supply:
210 W, 12 V, SFF, EPA92+
180 W, SFF, EPA90 (gold)
(3) Optical disc drive:
DVD BD-WRITER DRIVE (9.5 mm, UST, 6×)
DVD+/-RW SM DL DRIVE (9.5 mm, slim, tray load)
DVD-ROM DRIVE (9.5 mm, slim, tray load)
ENWW 5
