HP ProLiant BL30p

Server Blade Troubleshooting
Figure A-1: Blade sleeve board and server blade LED
locations (shown with blade sleeve cover removed)
Table A-6: Blade Sleeve Board and Server Blade LED Locations
LED LED Name (System Board Descriptor)
1 Blade sleeve power LED (CR6)
2 Power converter module LED (CR9)
3 FC LED (CR3)
4 Blade sleeve power LED (CR7)
A-14 HP ProLiant BL30p Server Blade Setup and Installation Guide
