HP ProLiant BL30p

Hardware Options Installation
Installing Hard Drives
1. Disconnect the hard drive cable from the system board by pulling the tab on the
hard drive cable straight up and away from the connector (1).
2. Loosen the drive cage assembly thumbscrew (2).
3. Rotate the drive cage assembly up and away from the server blade (3).
NOTE: If a hard drive is already installed in the drive cage assembly, disconnect the hard
drive cable from the hard drive. If a hard drive is not installed in the drive cage assembly,
the hard drive cable will only be attached to the system board.
Figure 4-7: Removing the drive cage assembly
HP ProLiant BL30p Server Blade Setup and Installation Guide 4-7
