44 HP ProLiant DL360 Generation 4 Server Maintenance and Service Guide
CAUTION: To prevent possible server malfunction or damage
to the equipment, be sure to align the processor pins with the
corresponding holes in the socket.
3. Install the processor and close the processor locking lever and processor
retaining clips.
4. Rotate the baffle into position
5. Install the access panel.
