Cabling 105
• Mini-SAS Y-cable connected to the P430 storage controller option
Item Description
1
Power cable
2
Mini-SAS Y-cable
• Mini-SAS Y-cable connected to the P830 storage controller option
Item Description
1
Power cable
2
Mini-SAS Y-cable
