HP ProLiant DL380e Gen8 - Illustrated Parts Catalog; Mechanical Components

Illustrated parts catalog 16
Illustrated parts catalog
Mechanical components
HP continually improves and changes product parts. For complete and current supported parts information,
see the HP PartSurfer website (http://partsurfer.hp.com).
Item Description
Spare part
number
Customer self
repair (on page
6
)
1
Secondary PCI riser cage 688037-001 Optional
2
2
Primary PCI riser cage 684895-001 Optional
2
3
GPU retaining brackets 684901-001 Mandatory
1
a) Secondary GPU bracket — —
b) Primary GPU bracket — —
4
Access panel — —
a) Access panel for the 8 LFF, 8 SFF, and 8+8 SFF drive models 687951-001 Mandatory
1
b) Access panel for the 12 LFF and 25 SFF drive models* 687952-001 Mandatory
1
5
Air baffle 684891-001 Mandatory
1
