HP ProLiant DL380e Gen8 - 8+8 SFF Cabling

Cabling 106
8+8 SFF cabling
• Mini-SAS cables connected to a storage controller option installed in the primary PCI riser cage
Item Description
1
Power cable
2
Mini-SAS cables
• Mini-SAS cables connected to a storage controller option and a riser board with SAS support installed
in the primary PCI riser cage
Item Description
1
Power cable
2
Mini-SAS cables to the storage controller option
3
Mini-SAS cables to a riser board with SAS support
