Removal and replacement procedures 42
To install the component:
1. Install the new optical drive cage. Only the redesigned optical drive cage is available for spare
installation.
2. Perform steps 1-5 of the removal procedure in reverse sequence to complete the new optical drive cage
installation.
Air baffle
To remove the component:
CAUTION: For proper cooling, do not operate the server without the access panel, baffles,
expansion slot covers, or blanks installed. If the server supports hot-plug components, minimize
the amount of time the access panel is open.
1. Power down the server (on page 31).
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Do one of the following:
o Extend the server from the rack (on page 32).
o Remove the server from the rack (on page 34).
4. Remove the access panel ("Access panel" on page 37).
