HP ProLiant DL380e Gen8 - LFF Rear Drive Cabling

HP ProLiant DL380e Gen8
130 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
Cabling 112
2 LFF rear drive cabling
• Sideband signal and SATA cables connected to the system board
Item Description
1
Power cable
2
Sideband signal cable
3
SATA cable
• Sideband signal and SATA cables connected to the expander backplane
Item Description
1
SATA cable
2
Power cable
3
Sideband signal cable
