Cabling 104
8 SFF cabling
• Mini-SAS cables connected to a riser board with SAS support
Item Description
1
Power cable
2
Mini-SAS cables
• Mini-SAS cables connected to a storage controller option
Item Description
1
Power cable
2
Mini-SAS cables
