Cable Description
System board HPE Smart Storage battery Orange
Processor mezzanine tray HPE Smart Storage
battery
Blue
Eight-bay SFF HDD drive cage cabling
To cable the drive cage to the HPE 12G SAS Expander, see "Installing the HPE 12G SAS Expander Card
on page 96."
Drive box 1 cabling
Connected to the Primary PCIe riser board
Connected to the secondary PCIe riser board
Connected to the tertiary PCIe riser board
110 Eight-bay SFF HDD drive cage cabling
