HP ProLiant DL585

Illustrated Parts Catalog
Mechanical Components Spare Parts List
Table 1-1: Mechanical Components Spare Parts List
Item Description Assembly
Number
Spare Part
Number
Customer
Self Repair
(Yes/No)
1 Access panel 321466-001 359772-001 Yes
2 Front bezel 233588-001 243669-001 Yes
3 SCSI hard drive blank 349448-001 122759-001 Yes
4 SCSI hard drive
4a 18.2-GB SCSI hard drive,
U320 15K*
271837-015 289240-001 Yes
4b 36.4-GB SCSI hard drive,
U320 10K*
271837-007 289041-001 Yes
4c 36.4-GB SCSI hard drive,
U320 15K*
271837-016 289241-001 Yes
4d 72.8-GB SCSI hard drive,
U320 10K*
271837-008 289042-001 Yes
4e 72.8-GB SCSI hard drive,
U320 15K*
271837-018 289243-001 Yes
4f 145.6-GB SCSI hard drive,
U320 10K*
271837-010 289044-001 Yes
4g 300-GB SCSI hard drive,
U320 10K*
271837-021 351126-001 Yes
5 Power supply blank 233685-001 267133-001 Yes
6a Power supply, 800 W, hot-plug 192147-001 192201-001 Yes
6b Power supply, 870 W, hot-plug
(2.6 GHz model)
192147-002 192201-002 Yes
7 Power cord retainer kit* 313825-001 Yes
* Not shown
HP ProLiant DL585 Server Maintenance and Service Guide 1-3
