HP ProLiant DL585 - Locating the Processor Memory Boards; Processor Memory Boards

Removal and Replacement Procedures
Figure 2-8: Locating the processor memory boards
Table 2-1: Processor Memory Boards
Item Description
1 Processor memory board slot 1 (processor)
2 Processor memory board slot 2 (boot processor)
3 Processor memory board slot 3 (air baffle)
4 Processor memory board slot 4 (air baffle)
HP ProLiant DL585 Server Maintenance and Service Guide 2-11
