Illustrated Parts Catalog
Table 1-2: System Components Spare Parts List continued
Item Description Assembly Number Spare Part Number Customer Self
Repair (Yes/No)
10a Heatsink 321961-001 359774-001 Yes
10b Heatsink 321961-005 383420-001 Yes
11a Processor power module (PPM) 345746-002 365873-001 Yes
11b Processor power module (PPM),
(2.6 GHz)
383265-001 383337-001 Yes
12 Cable kit 243670-001 Yes
13 Battery, system, 3 V 166899-001 153099-001 Yes
14 5i Plus cache memory module 011665-001 260741-001 Yes
15 Battery-Backed Write Cache
Module, 4.8 V
011668-001 260740-001 Yes
16* Battery-Backed Write Cache Module
Cable
262695-004 283033-001 Yes
17 Fan assembly, hot-plug, 92 x 38 mm 321520-001 359773-001 Yes
18 Fan cage cable assembly* 321518-001 361442-001 No
19 Plastics kit* 359768-001 Yes
a) Processor memory board air
baffle
337992-001
b) Chassis air baffle, lower 338886-001
c) Chassis air baffle, upper 333359-001
20 AC power cord, 15 A, 125 V* 178968-001 237457-001 Yes
21 AC power cord, 20 A, 250 V* 177857-001 237458-001 Yes
22 AC power cord, 16A, C19-C20* 242867-001 295508-001 Yes
23 AC power cord, 10A, C14-C19 IEC* 287485-001 311582-001 Yes
24 Rack-mounting hardware kit
(square-hole rack)*
284499-002 313215-001 Yes
25 Rack-mounting hardware kit (round-
hole rack)* optional
287528-B21 291895-001 Yes
26 Cable kit, AC filter cable assembly* 243671-001 No
27 Torx screwdriver, T-15* 107473-001 199630-001 Yes
28 Return kit* 273444-001 279645-001 Yes
*Not shown
continued
1-6 HP ProLiant DL585 Server Maintenance and Service Guide
