Power supply cablingPower supply cabling

Non-hot-plug power supply cablingNon-hot-plug power supply cabling

Cable colorCable color DescriptionDescription

Orange 24-pin power supply cable

Blue 4-pin power supply cable

Flexible Slot power supply cablingFlexible Slot power supply cabling

Cable colorCable color DescriptionDescription

Power supply cabling 179
