Install the air baffleInstall the air baffle
CAUTION: CAUTION: For proper cooling, do not operate the server without the access panel, baffles, expansion slot covers, or
blanks installed. If the server supports hot-plug components, minimize the amount of time the access panel is open.
ProcedureProcedure
1. Install the air baffle:
a. Insert the tabs on the baffle into the slots on the rear chassis.
b. Press the front end of the baffle into the chassis.
2. Install the access panel
.
3. Install the front bezel
.
4. Do one of the following:
If the server is in tower mode: Position the tower server for operation .
If the server is in rack mode: Install the server on the tray .
5. Connect all peripheral cables to the server.
6. Connect the power cords:
a. Connect each power cord to the server.
b. Connect each power cord to the power source.
7. Power up the server
.
